Pharmaceutical Medical Laboratory Machines / Drug Dissolution Test Apparatus

Range of application:

It’s used to examine the dissolving speed and degree of solid preparations like drug tablets or capsules in the specified solvents. RC-12 dissolution tester is a kind of new type drug dissolution tester which is developed and produced by our company; it adopts classical modeling design and is featured by high cost performance, stability, reliability, simple operation and durability.

Main features:

• RC-12 The head moves up/down automatically..
• Available for installation of 12 basket rods or paddle rods.
• Available for installation of 12 new dissolution cups with the height of 185mm and shading dissolution cups as well.
• Friendly human-computer interface, with simple and convenient operation.
• All the working parameters can be preset and saved automatically, without the need to set repeatedly when the instrument is started next time
• Accurate rotating speed, steady operation and low energy consumption.
• Thermostatic water bath adopts built-in integrated temperature sensor and new software and hardware temperature measurement and control mode, which is featured by fast temperature rise and high precision; temperature deviation can be corrected with software conveniently.
• Independent operation of startup, pause and reset for experimental timing.
• Automatic protection functions such as self-inspection fault alarm and over-temperature protection, etc.
• The paddle rod, basket rod and basket turning body are all made of stainless steel material meet the requirements of Chinese
• Pharmacopoeia in quality and performance.

Main technical indexes of dissolution tester:

▓ Amplitude of swing of stirring paddle: ≤0.3mm

▓ Amplitude of swing of rotation basket: ≤0.8mm

▓ Deviation of rotating rod and axle of dissolution cup:≤1mm

▓ Speed adjustable range: 20-200 rpm

▓ Rotating speed resolution:1 time/min

▓ Water bath temperature adjustment range:room temperature: -45ºC

▓ Temperature resolution:0.1ºC

▓ Temperature control accuracy:≤±0.3ºC

▓ Number of sampling periods: 9 different sampling periods can be preset.

▓ Time of sampling period:1-999min optional for each period,9 sampling periods can be counted down by sections.

▓ Timing error:±0.5min

▓ Pharmacopoeia parameter calling:The instrument saves 300 dissolution test parameters in Chinese Pharmacopoeia, which can be called randomly.

▓ Large screen liquid crystal display and intelligent menu operation.

▓ The head can lift and descend automatically and attaches overturn function (a model whose control is very convenient).

▓ Electronic sensor can monitor the temperatures of various point of water bath case.

▓ Standard configuration:12 paddles and 12cups

▓ Electrical heating power:1100W
